Harman/Kardon

Harman Kardon Citation Bar

Details
Variations

Den smarteste soundbar til film og musik

DKK 7.999,007999.0 pr.styk
Product Actions
Add to cart options

På lager. Forventet leveringstid er 2-3 hverdage

Stilren lyd der taler til dig

Harman Kardon Citation Bar er en smart næste-generations soundbar til film og musik med en brugervenlig touch-skærm i farver. Den innovative soundbar kombinerer lydtekniske nyskabelser med et sofistikeret design med sans for de mindste detaljer. Her får du fantastisk bas uden en subwoofer. Musiknydere vil elske adgangen til over 300 musiktjenester og HD-streaming via Chromecast built-in. Filmelskere vil elske deres helt trådløse 5.1 hjemmebiograf med Citation Surround og Citation Sub. Google Assistent leverer praktisk talestyring, så Citation Bar bliver din håndfri hjælper i hjemmet. Få svar, spil musik, planlæg din dag, styr dit smarte hjem, nyd din underholdning og meget mere - alt sammen med din stemme!

Specifikationer

Enhed 3 x 20mm diskant, 6 x (100 x 50) racetrack bas
Udgangseffekt 150W RMS
Signal til støj-forhold >80dB
Strømforsyning 100-240V~50/60Hz
Strømforbrug i dvaletilstand <2.0 Watt
Trådløst netværk 802.11 a/b/g/n/ac (2,4GHz/5GHz)
Frekvensområde for 2,4G wi-fi-sender 2412 – 2472MHz (2,4GHzISM-bånd, USA 11 kanaler, Europa og andre steder 13 kanaler)
2,4G wi-fi-sendeeffekt <20dBm
2,4G wi-fi-modulation DBPSK, DQPSK, CCK, QPSK, BPSK, 16QAM, 64QAM
5G wi-fi-sendeeffekt <23dBm
5G wi-fi-modulation QPSK, BPSK, 16QAM, 64QAM, 256QAM
Frekvensområde for 5G wi-fi-sender 5,15 - 5,35GHz, 5,470 - 5,725GHz, 5,725 - 5,825GHz
Bemærk CITATION BAR er beregnet til trådløs afspilning af musik. Man kan afspille musik via Bluetooth på højttaleren. Man kan forbinde sin højttaler til det lokaleWi-Fi-netværk og afspille musik med Google Chromecast. Højttaleren fungerer også sammen med Google Home. Dette produkt er designet til at være tændt med det samme og klar til at afspille musik på et øjeblik. Derfor skal Bluetooth ogWi-Fi være aktivt til enhver tid for at sikre, at produktet fungerer korrekt. CITATION BAR er i overensstemmelse med EU's energilovgivning. CITATION BAR Den går i standby-tilstand (netværks-standby) efter 20 minutters inaktivitet, hvorefter den kan genaktiveres via Bluetooth ellerWi-Fi.

Audio Specifications

Signal-to-noise ratio >80dB
Output power 150W RMS
Transducer 3 x 20mm tweeter, 6 x (100 x 50) racetrack woofer

Dimensions

Mål (B x H x D) 1150 x 64 x 115mm (45” x 2,4” x 4,5”)
Vægt: 4,1kg (9lb) Ja

Control and Connection Specifications

Bluetooth® version 4.3
Frekvensområde for Bluetooth-transmitter 2402 – 2480MHz
Bluetooth-sendeeffekt <10dBm
Bluetooth-sendemodulation GFSK,π/4 DQPSK, 8DPSK
  • 1 x Citation Bar
  • 1 x Lynguide
  • 1 x Garantikort
  • 1 x Sikkerhedsark
  • 1 x strømkabel (1,8m)
{"searchRecords":[{"attributes":{"type":"Knowledge__kav","url":"/services/data/v45.0/sobjects/Knowledge__kav/ka21Y000000SWIaQAO"},"Title":"HK CITATION: Controlling IOT devices","Id":"ka21Y000000SWIaQAO","ArticleNumber":"000009698","Question__c":"Can I control iOT devices with my Citation speaker?","Answer__c":"Citation will work with any smart home or iOT device labeled Works with Google Assistant.\r\n\r\n\r\nVisit http://assistant.google.com to learn more.","ArticleType":"FAQ__kav"},{"attributes":{"type":"Knowledge__kav","url":"/services/data/v45.0/sobjects/Knowledge__kav/ka21Y000000SVLaQAO"},"Title":"HK Citation: Recording conversation","Id":"ka21Y000000SVLaQAO","ArticleNumber":"000008776","Question__c":"Does the Citation speaker record all my conversations?","Answer__c":"No, the Citation speaker does not store any conversations, it listens only for a few seconds and then deletes the file. Only when using \"OK, Google\" or \"Hey, Google\" will it start recording your question in order for Google Assistant to fulfill your request. You can always delete all your recordings via \"My activity\" settings under your Google Account.","ArticleType":"FAQ__kav"},{"attributes":{"type":"Knowledge__kav","url":"/services/data/v45.0/sobjects/Knowledge__kav/ka21Y000000SWINQA4"},"Title":"HK CITATION: Resetting speakers","Id":"ka21Y000000SWINQA4","ArticleNumber":"000009663","Question__c":"How can I factory reset my Citation device?","Answer__c":"For Citation ONE, Citation 100, Citation Sub and Citation Surround, Press and hold the RESET button on the speaker for 5 seconds.\r\n\r\nFor Citation 300, Citation 500, Citation Bar and Citation Tower, Press and hold the RESET button on the speaker for 5 seconds, or select the Factory Reset option in the touch screen settings menu.","ArticleType":"FAQ__kav"},{"attributes":{"type":"Knowledge__kav","url":"/services/data/v45.0/sobjects/Knowledge__kav/ka21Y000000SX87QAG"},"Title":"HK CITATION: Programmable Presets","Id":"ka21Y000000SX87QAG","ArticleNumber":"000010831","Question__c":"How to create and add Presets","Answer__c":"In our latest update for Citation, we added a couple of new features.
We are going to talk about our new programmable preset feature.

With this feature, you can add a voice command such as "Turn off the lights in the Bedroom" or "Play my playlist Rock road classic" without using your voice.
Once you have recorded the action, you will see an icon on your Citation display. Tap on this specific recorded command, and the Citation will do all the magic for you!

Enough of what it can do, let us create a preset:\n
  1. Scroll down on your Citation Display to you see "Voice presets."
  2. Press on the + sign.
  3. Say your command: Play Radio FM\n\t
    1. Do not use "Hey or OK, Google at this point."
    \n\t
  4. Press the "V" icon after the command is finished.
  5. Select an icon.
  6. Your Preset is now ready, tap it to give it a try.
\nTo delete any presets.\n\n
  • Press and hold down the preset.
  • A menu will appear, hit the "TRASHCAN" icon.
","ArticleType":"How_Tos__kav"},{"attributes":{"type":"Knowledge__kav","url":"/services/data/v45.0/sobjects/Knowledge__kav/ka21Y000000SWIOQA4"},"Title":"HK CITATION: Removing Towers from Surround setup","Id":"ka21Y000000SWIOQA4","ArticleNumber":"000009669","Question__c":"How to remove Citation Towers from a Surround setup and reinstalling them again?","Answer__c":"Perform a factory reset on the Citation Tower speakers by pressing and holding the reset button on the back panel for 5 seconds.\r\nAfter the reset you can now select \"Music\" to set up the Tower speakers to your WiFi network.","ArticleType":"FAQ__kav"},{"attributes":{"type":"Knowledge__kav","url":"/services/data/v45.0/sobjects/Knowledge__kav/ka21Y000000SVM8QAO"},"Title":"HK Citation: BAR not responding to voice","Id":"ka21Y000000SVM8QAO","ArticleNumber":"000008784","Question__c":"I am using AUX-in, Optical, or HDMI with my Citation Bar, and Google Voice Assistant does not respond. How can I use Google Voice Assistant?","Answer__c":"Use the Google Voice Assistant button on your Citation Bar remote control when using these inputs HDMI, AUX or Optical. When you press this button, the current volume level will temporarily decrease and the Google Voice Assistant will begin listening for your command. \r\nThe reason you need to use the remote control is that Google Assistant does not support Multi-channel audio from your source device (TV, BlueRay Player or TV-BOX) and therefore the mic is automatically muted unless the Google Voice Assistant button is pressed.\r\nThis may be different in the future with new software updates.\r\n\r\nGoogle Voice Assistant is always listening when streaming music over Wi-Fi or Bluetooth.","ArticleType":"FAQ__kav"},{"attributes":{"type":"Knowledge__kav","url":"/services/data/v45.0/sobjects/Knowledge__kav/ka21Y000000SWIUQA4"},"Title":"HK CITATION: Low budget Android phones","Id":"ka21Y000000SWIUQA4","ArticleNumber":"000009699","Question__c":"I am using an Android phone and cannot set up my Citation speaker","Answer__c":"Please try turning Bluetooth off on your phone and trying again, and make sure Location services are enabled for the Google Home app.\r\n\r\nIf this does not work, certain phones are not compatible with the Google Home setup process, including the Vivo X21A, Vivo NEX S, and Vivo X9. Please use a different device for setup.","ArticleType":"FAQ__kav"},{"attributes":{"type":"Knowledge__kav","url":"/services/data/v45.0/sobjects/Knowledge__kav/ka21Y000000SWIfQAO"},"Title":"HK CITATION: Using Google Voice in Surround systems","Id":"ka21Y000000SWIfQAO","ArticleNumber":"000009689","Question__c":"I have a Surround sound system with other Citation speakers. How can I use Google Voice Assistant?","Answer__c":"Use the Google Voice Assistant button on your Citation Bar remote control when using these inputs. When you press this button, the current volume level will temporarily decrease and the Google Voice Assistant will begin listening for your command. \r\n\r\nIf you wish to use Google Voice Assistant with the wake-up word when steaming music over Wi-Fi or Bluetooth in a 5.1 surround sound system, turn off the Surround setting on the Citation Bar touch screen.","ArticleType":"FAQ__kav"},{"attributes":{"type":"Knowledge__kav","url":"/services/data/v45.0/sobjects/Knowledge__kav/ka21Y000000SWIjQAO"},"Title":"HK CITATION: WiFi out of range","Id":"ka21Y000000SWIjQAO","ArticleNumber":"000009674","Question__c":"My Citation speaker said it needs to be set up, but I have already set it up and it was working previously.","Answer__c":"Make sure your home network's Internet connection is active and the Citation speaker is placed within Wi-Fi range.\r\n\r\nIf you are using a Wi-Fi extender, your speaker may be confused which network to connect to. If this is happening, try moving the speaker closer to the main router and renaming the Wi-Fi extender.","ArticleType":"FAQ__kav"},{"attributes":{"type":"Knowledge__kav","url":"/services/data/v45.0/sobjects/Knowledge__kav/ka21Y000000SVLzQAO"},"Title":"HK Citation: 4 Amber LEDS","Id":"ka21Y000000SVLzQAO","ArticleNumber":"000008757","Question__c":"The 4 LED dots change to amber on my Citation speaker. What does this mean?","Answer__c":"The amber LED lights indicate that the microphone is muted and the Google Assistant will not react to any voice keywords until the microphone is unmuted.","ArticleType":"FAQ__kav"},{"attributes":{"type":"Knowledge__kav","url":"/services/data/v45.0/sobjects/Knowledge__kav/ka21Y000000SWIiQAO"},"Title":"HK CITATION: Wi-Fi protocol support","Id":"ka21Y000000SWIiQAO","ArticleNumber":"000009656","Question__c":"What Wi-Fi standards are supported for Citation?","Answer__c":"Citation speakers support 802.11g, 802.11n, and 802.11ac standards on both 2.4 GHz and 5 GHz bands. We recommend using 5 GHz if available, as this will give you more stable performance and use the full power of your wireless audio.\r\n\r\nContact our customer support to get in touch with an expert that can help you with your Wi-Fi network. We are here to help!","ArticleType":"FAQ__kav"},{"attributes":{"type":"Knowledge__kav","url":"/services/data/v45.0/sobjects/Knowledge__kav/ka21Y000000SWIQQA4"},"Title":"HK CITATION: Multiple devices reacting to voice","Id":"ka21Y000000SWIQQA4","ArticleNumber":"000009657","Question__c":"What happens if you have multiple Citation speakers, will all react to \"Hey Google\" or \"OK Google\"?","Answer__c":"All speakers are set to react when you use the keywords to interact with Google. To eliminate multiple speakers talking at the same time, using the \"Microphone Mute\" button will stop the speaker from reacting to the keywords.","ArticleType":"FAQ__kav"},{"attributes":{"type":"Knowledge__kav","url":"/services/data/v45.0/sobjects/Knowledge__kav/ka21Y000000SXL9QAO"},"Title":"HK CITATION: Frequency response for speakers","Id":"ka21Y000000SXL9QAO","ArticleNumber":"000010972","Question__c":"What is the Frequency response of the Citation series?","Answer__c":"The Frequency response for the Citation series is 20Hz to 20Khz.","ArticleType":"How_Tos__kav"}]}
